| Model(option) | QN1325G |
| Working area | 1300*2500 |
| Z axis (option) | 150mm |
| Cutting thickness | 0.3-30mm |
| Rotary | 250*2000mm |
| Structure | Cast steel structure |
| Control system | start control system |
| Guide rail | TaiWan Square rails |
| Cutting speed | 0-9500mm/min |
| Cutting precision | <=0.01mm |
| Drive motor | stepper motor |
| Cutting mode | Plasma |
| Driving motor | stepper |
| Working current | 100A/200A |
| Input voltage | 3 phase 380V or 220V |
| Power frequency | 50Hz/60HZ |
| Command code | G Code*、U00*、mmg*、nc |
| Interface | USB |
| Working temperature | —10ºC-45℃ |
| Application | steel, iron, aluminum, mild steel, and other metal steel. |
| Standard parts |
Gantry cast steel structure stepper motor and driver start control system Taiwan square guide rail water cooling and protection system plasma Arc Voltage Height Adjusting CD video,user manual,design software,soft dog |
